Standard Sintered Filter 5 Layers

Standard Sintered Filter – 5 Layers
Model	Filter Rating ( u)	Structure	Thickness (mm)	Air Permeability (L/min/cm2)	Bubble Pressure (mm H2O)	Weight  (kg/m2)	Porosity (%)
S5001	1	100+400X2800+100+12X64+64X12	1.7	1.81	360-600	8.4 KG	37%
S5002	2	100+325X2300+100+12X64+64X12	1.7	2.35	300-590
S5005	5	100+200X1400+100+12X64+64X12	1.7	2.42	260-550
S5010	10	100+165X1400+100+12X64+64X12	1.7	3.00	220-500
S5015	15	100+165X1200+100+12X64+64X12	1.7	3.41	200-480
S5020	20	100+165X800+100+12X64+64X12	1.7	4.50	170-450
S5025	25	100+165X600+100+12X64+64X12	1.7	6.12	150-410
S5030	30	100+450+100+12X64+64X12	1.7	6.70	120-390
S5040	40	100+325+100+12X64+64X12	1.7	6.86	100-350
S5050	50	100+250+100+12X64+64X12	1.7	8.41	90-300
S5075	75	100+200+100+12X64+64X12	1.7	8.70	80-250
S5100	100	100+150+100+12X64+64X12	1.7	9.10	70-190

Standard Sintered Filter 6 Layers

Standard Sintered Filter – 6 Layers
Model	Filter Rating ( u)	Structure	Thickness (mm)	Air Permeability (L/min/cm2)	Bubble Pressure (mm H2O)	Weight  (kg/m2)	Porosity (%)
S6001	1	100+400X2800+100+12X64+64X12+12	3.5	1.81	360-600	14.4 KG	37%
S6002	2	100+325X2300+100+12X64+64X12+12	3.5	2.35	300-590
S6005	5	100+200X1400+100+12X64+64X12+12	3.5	2.42	260-550
S6010	10	100+165X1400+100+12X64+64X12+12	3.5	3	220-500
S6015	15	100+165X1200+100+12X64+64X12+12	3.5	3.41	200-480
S6020	20	100+165X800+100+12X64+64X12+12	3.5	4.5	170-450
S6025	25	100+165X600+100+12X64+64X12+12	3.5	6.12	150-410
S6030	30	100+450+100+12X64+64X12+12	3.5	6.7	120-390
S6040	40	100+325+100+12X64+64X12+12	3.5	6.86	100-350
S6050	50	100+250+100+12X64+64X12+12	3.5	8.41	90-300
S6075	75	100+200+100+12X64+64X12+12	3.5	8.7	80-250
S6100	100	100+150+100+12X64+64X12+12	3.5	9.1	70-190
