Specification Table Twill Weave

Dutch Twill Weave Stainless Steel Wire Mesh Specification
Mesh/Inch		Wire Diameter				MicronRetention
Warp	Weft	Warp (mm)	Warp (inch)	Weft (mm)	Weft (inch)	Abs. μm	nom.μm
20	250	0.249	0.0098	0.201	0.0079	110-120	98-105
30	360	0.249	0.0098	0.152	0.0060	90-100	80-84
40	560	0.178	0.007	0.102	0.0040	70-75	47-52
80	700	0.102	0.004	0.076	0.0030	35-40	24-26
120	400	0.102	0.004	0.064	0.0025	50-55	37-43
120	160	0.102	0.004	0.064	0.0025	40-45	28-32
165	800	0.071	0.0028	0.051	0.0020	24-26	14-16
165	1400	0.071	0.0028	0.041	0.0016	16-18	9-11
200	600	0.061	0.0024	0.046	0.0018	28-32	19-21
200	1400	0.071	0.0028	0.041	0.0016	12-14	5-6
250	1400	0.056	0.0022	0.041	0.0016	11-12	3-4
325	2300	0.038	0.0015	0.025	0.0010	8-9	2-3

Twill Weave Stainless Steel Wire Mesh Specification
Mesh	SWG	Nominal Aperture		Wire Diameter		Open Area
/Inch	No.	MM	Inch	MM	Inch	%
250	48	0.062	0.0024	0.040	0.0016	37%
300	48	0.045	0.0018	0.040	0.0016	84%
325	48.5	0.043	0.0017	0.035	0.0014	30%
350	49	0.04	0.0016	0.032	0.0013	29%
400	49	0.034	0.0013	0.030	0.0012	28%

Reverse Dutch Weave Stainless Steel Wire Mesh Specification
Mesh/Inch		Wire Diameter				Mesh Thickness
Warp	Weft	Warp (mm)	Warp (inch)	Weft (mm)	Weft (inch)	MM
72	15	0.500	0.0197	0.500	0.0197	1.8
132	14	0.355	0.0140	0.450	0.0177	1.4
132	18	0.355	0.0140	0.450	0.0177	1.4
152	24	0.315	0.0124	0.355	0.0140	1.04
228	36	0.190	0.0075	0.280	0.0110	0.85
